FDP26-115X Series
7,000 and 9,000 BTU/h cooling and heating capacity
Available models · 2
- Cooling Capacity
- 2600 W/9000 BTU
- Air Flow
- 350 m³/h
- Noise Level
- ≤54 dB(A)
Specification matrix
Values are listed per model in the FDP26-115X platform. Scroll horizontally to compare models.
| Parameter | FDP26-115X | FDP(H)26-115X |
|---|---|---|
| Voltage/Frequency | 220-240V/50Hz | 220-240V/50Hz |
| Cooling Capacity | 2600 W/9000 BTU | 2600 W/9000 BTU |
| Heating Capacity | / | 2000 W |
| Power Input (Cooling) | 950 W | 950 W |
| Power Input (Heating) | / | 750 W |
| EER | 2.6 | 2.6 |
| Humidity Extraction | 1.2 L/H | 1.2 L/H |
| Air Volume | 350 m³/h | 350 m³/h |
| Noise Level | ≤54 dB(A) | ≤54 dB(A) |
| Refrigerant | R290/R410A | R290/R410A |
| Product Meas. | 367×353×684 mm | 367×353×684 mm |
| Package Meas. | 410×410×870 mm | 410×410×870 mm |
| Loading Qty. (pcs) | 20FCL: 140, 40FCL: 290, 40HQFCL: 430 | 20FCL: 140, 40FCL: 290, 40HQFCL: 430 |
| N.W. | 24 kg | 25 kg |
| G.W. | 26 kg | 27 kg |
Values follow the current product catalogue and can be adjusted to the destination market. Final figures are confirmed on the proforma invoice.
Packing & loading reference
One row per model in the FDP26-115X platform, so you can plan cartons, weights and container loading before you confirm a shipment.
| Model | Product size | Carton size | Net weight | Gross weight | Qty / 20'GP | Qty / 40'GP | Qty / 40'HQ |
|---|---|---|---|---|---|---|---|
| FDP26-115X | 367×353×684 mm | 410×410×870 mm | 24 kg | 26 kg | 140 | 290 | 430 |
| FDP(H)26-115X | 367×353×684 mm | 410×410×870 mm | 25 kg | 27 kg | 140 | 290 | 430 |
Container quantities are quoted as pieces per container based on the standard carton. Mixed-model loading and palletised shipping are recalculated on the proforma invoice.
Design & key features
FDP26-115X Series is a portable air conditioning platform covering 2 models (FDP26-115X, FDP(H)26-115X). Cooling capacity spans 2600 W/9000 BTU. Design highlights include 7,000 and 9,000 btu/h cooling and heating capacity; environmentally friendly r410a or r290 refrigerant; 3-in-1: air conditioner, fan cooler and dehumidifier.
- 7,000 and 9,000 BTU/h cooling and heating capacity
- Environmentally friendly R410A or R290 refrigerant
- 3-in-1: air conditioner, fan cooler and dehumidifier
- 3-speed control from panel or remote control
- High energy efficiency, EER: A class
- Horizontal swing louvers for enhanced cooling performance
- Virtually no installation necessary
- Up to 24 hours programmable timer
- Self-diagnose capability and water-full safety alarm
- Easy to move around on rolling casters
- Removable air filter for easy cleaning
- Optional WIFI function
- Extendable exhaust hose up to 1.5 meters
Request pricing for FDP26-115X
Tell us the model you need, the quantity, plug type, certification and destination port. Our export team replies with pricing, MOQ and lead time within one business day.
